Specification
| MODEL | EP30-8KW | EP30-10KW | EP30-12KW | ||||
|---|---|---|---|---|---|---|---|
| Default Battery System Voltage | 48VDC | 48VDC | 48VDC | ||||
| INVERTER OUTPUT | Continuous output power | 8.0KW | 10.0KW | 12.0KW | |||
| Surge rating (20ms) | 24.0KW | 30.0KW | 36.0KW | ||||
| Capable Of Starting Electric Motor | 4HP | 5HP | 6HP | ||||
| Output waveform | Pure sine wave/ same as input (bypass mode) | ||||||
| Inverter Efficiency(Peak) | >88% | ||||||
| Line mode efficiency | >95% | ||||||
| Power factor | 1.0 | ||||||
| Nominal output voltage RMS | 220V/230V/240VAC(+/-10% RMS) | ||||||
| Output frequency | 50Hz/60Hz +/-0.3 Hz | ||||||
| Short circuit protection | Yes (1sec after fault) | ||||||
| Typical transfer time | 10ms(max) | ||||||
| AC INPUT | Voltage | 230VAC | |||||
| Selectable Voltage Range | 155~280VAC(For Personal Computers) | ||||||
| Frequency Range | 50HZ/60HZ (Auto sensing) | ||||||
| BATTERY | Minimum start voltage | 20.0VDC/21.0VDC for24VDC mode (40.0VDC/42.0VDC for 48VDC mode) | |||||
| Low battery alarm | 21.0VDC+/-0.3V for 24VDC mode (42.0VDC+/-0.6V for 48VDC mode) | ||||||
| Low battery Cutoff | 20.0VDC+/-0.3V for 24VDC mode (40.0VDC+/-0.6V for 48VDC mode) | ||||||
| High voltage alarm | 32.0VDC+/-0.3V for 24VDC mode (64.0VDC+/-0.6V for 48VDC mode) | ||||||
| High battery voltage recover | 31.0VDC+/-0.3V for 24VDC mode (62.0VDC+/-0.6V for 48VDC mode) | ||||||
| Idle consumption-search mode | <35W when power saver on | ||||||
| CHARGER | Output voltage | Depends on battery type | |||||
| Charger AC input breaker rating | 40A | 50A | 63A | ||||
| Max charge power rate | 1/3 Rating power | ||||||
| Overcharge protection S.D. | 62.8VDC | ||||||
| Maximum Charge Current | 70A | 80A | 100A | ||||
| BTS | Temperature rate @25°C | 4mv charging voltage descent, per 1°C rise | |||||
| BYPASS & PROTECTION |
Input voltage waveform | Sine wave (grid or generator) | |||||
| Nominal voltage | 220V/230V/240VAC | ||||||
| Max input AC voltage | 300VAC for 230VAC HV mode | ||||||
| Nominal input frequency | 50Hz or 60Hz | ||||||
| Overload protection (SMPS load) | Circuit breaker | ||||||
| Output short circuit protection | Circuit breaker | ||||||
| Bypass breaker rating | 80A | ||||||
| Max bypass current | 80Amp | ||||||
| MECHANICAL SPECIFICATIONS | Mounting | Wall mount | |||||
| Inverter dimensions (W*H*D) | 670*410*215mm | ||||||
| Inverter weight (solar chg) KG | 67.5 | 74 | 74 | ||||
| Shipping dimensions(W*H*D) | 802*533*429.5mm | ||||||
| Shipping weight (solar chg) KG | 87 | 93.5 | 93.5 | ||||
| OTHER | Operation Temperature Range | 0°C to 40°C | |||||
| Storage Temperature | -15°C to 60°C | ||||||
| Audible Noise | 60dB MAX | ||||||
| Display | LED+LCD | ||||||
