Model |
GF500-HW |
GF1000-HW |
GF1000-HW |
GF1500-HW |
GF2000-HW |
| Power |
500W |
1000W |
1000W |
1500W |
2000W |
| Battery Voltage |
24Vdc |
48Vdc |
|||
| Working Mode |
PV(Photovoltaic priority) / AC (AC priority) Optional |
||||
| PV | |||||
| Input Voltage Range |
24Vdc – 45Vdc |
48Vdc – 90Vdc |
|||
| PV Panels Configuration
(Suggestion) (vmp) |
30Vdc – 36Vdc |
60Vdc – 71Vdc |
|||
| PV Panels Configuration(Suggestion)
(Imp≤rated current) |
≤40A |
≤60A |
≤40A |
≤60A |
≤80A |
| Max Charge Current |
10-40A Optional |
10-60A Optional |
|||
| Max Transfer Efficiency |
98% |
||||
| Display | |||||
| Display Panel |
LED |
||||
| Mains Status(option) | |||||
| Input Voltage Range |
100/110/120/220/230/240VAC±25％(customized) |
||||
| Input Frequency Range |
45-65Hz (over this range transfer to inverter model auto.) |
||||
| Output Voltage Range |
220Vac± 10% |
||||
| MAX Input PF (AC/DC) |
98% |
||||
| MAX Efficiency |
96% |
||||
| MAX Charge Current |
12A Max( battery discharge ends; Start charging when PV charge current less than the set value) |
||||
| AC Over Load |
110% load, after 255s, transfer to bypass,120% load ,after 60s transfer to bypass, 150% load, after 10s, transfer to bypass, auto recover after decrease load |
||||
| Short Circuit |
Input fuse / breaker |
||||
| Inverter Output | |||||
| Output Voltage |
220Vac± 5％ |
||||
| Output Frequency |
50 Hz / 60Hz ± 1% Auto. |
||||
| Output PF |
1.0 |
||||
| Distortion |
Line load≤ 5% |
||||
| PV-AC Transfer Time |
5 ms typical value; Max.8 ms |
||||
| Max Efficiency |
84.5% |
||||
| Nverter Overload |
110% load 255s shut down,120% load 60s shut down,150% load 1s shut down |
||||
| No Load Off (Optional) |
Load< 5% after 1min , transfer to bypass mode |
||||
| Short Circuit |
System Shut down automatically |
||||
| AC Abnormal |
Beeping 1/4s，auto silence after 40s |
||||
| Alarm | |||||
| Battery Low |
Beeping 5/ 1s |
||||
| Over Load |
1/ 1s |
||||
| Communication Port (optional) |
Rs232 / USB / SNMP(Setup available for regular start/shutoff) |
||||
| Dry Contact |
PV failure、battery low-voltage、overload、bypass、 inverter failure/ remote start generator dry contact signal |
||||
| Others | |||||
| Output Sockets |
RS232/USB/SNMP(Setup available for regular start/shutoff) |
||||
| Surge Protection |
Class |
||||
| EMC |
CEN62040-2:2006;EN61000-3-2:2006; EN61000-3-3:2008 |
||||
| IP Class |
IP55 |
||||
| Ambient Temperature |
0℃ ~ 40℃ |
||||
| Ambient Humidity |
10℃ ~ 90℃ (Non Condensed) |
||||
| Noise |
≤ 50dB |
||||
| Working Altitude |
2000m(Every 100m increase derating 1%) |
||||
| Inverter Size WxDxH(mm) |
280x600x900(with space for 2units 100A-200Ah battery) |
540x600x900 (with space for 4units 100A-200Ah battery) |
|||
| Packing Size WxDxH(mm) |
320x605x975 |
615x660x975 |
|||
